Bakery Machine 50 Kg Spiral Dough Mixer Flour Mixer

Model No.
S-150
Made in
Taiwan
Supplier
ATLAS STAR MACHINERY CO., LTD.More About This Product
Request for Quotation
Contact Supplier

Your Best Choice Dough Mixer Manufacturer.

Spec

  • Machine Size : 1260*720*1190 mm

Key Features

50 kg flour Spiral Mixer Dough Kneader (Taiwan Made)


Strong enough for bagels, gentle enough for artisan dough, Taiwan made Stationary Bowl Spiral Mixers are available in a wide range of sizes, and can mix from 20 and 440 lbs. of flour. Coordinated 2-Speed spiral and bowl rotation gives maximum control of ingredient blending, dough development and better end product.

Specifications


 Bowl Capacity
 116 Qt (110 Liter)
 Flour Capacity
 110 lbs (50 kg)
 Dough Capacity
 176 lbs (80 kg)
 Bowl Size
 26.3” x 16” (670*400 mm)
 Speeds
 2 Speed Spiral and Bowl Drive
 Timer
 2 Timers with auto changeover
 Spiral Arm Motor
 6 HP (4.474 KW)
 Bowl Motor
 0.75 HP
 Voltage
 3 phase for 220V-415V
 N. W.
 992 lbs (450 kg)
 Dimension
 48” x 28” x 47” (1220*720*1190 mm)
 Accessory
 1 x Stainless Steel Bowl
 1 x Stainless Steel Spiral Arm
 1 x Stainless Steel Breaker Bar
 1 x Stainless Steel Guard
 Country of Origin
 100% made in Taiwan
 Certified
 CE approval

Features

  • Reversible Bowl Rotation.
  • Two Timers with Automatic Changeover from Low to High Speed.
  • Heavy-duty agitator is 20% thicker than industry leader.
  • Hi-Speed Lock Out Switch to prevent high speed operation.
  • See-thru bowl guard with safety interlock prevents operation with guard open.
  • Belt driven Arm and Bowl for quick operation and low maintenance.
  • Heat treated enamel coating resists scratches, rust, and dents.
  • Mounted on castors for extra mobility and easy maintenance.



Others Spiral Mixer


Bowl Capacity
Flour Capacity
Dough Capacity
Voltage
S-0630 Liter6 Kg-Single phase for 220V
S-2030 Liter8 Kg12 KgSingle phase for 110V - 220V
S-8070 Liter25 Kg40 Kg3 phase for 220V - 415V
S-10090 Liter38 Kg60 Kg3 phase for 220V - 415V
S-150110 Liter50 Kg80 Kg3 phase for 220V - 415V
S-200 Heavy180 Liter75 Kg120 Kg3 phase for 220V - 415V
S-200180 Liter75 Kg120 Kg3 phase for 220V - 415V
S-200A225 Liter75 Kg120 Kg3 phase for 220V - 415V
S-250210 Liter100 Kg150 Kg3 phase for 220V - 415V
S-250A225 Liter100 Kg150 Kg3 phase for 220V - 415V
S-300240 Liter125 Kg200 Kg3 phase for 220V - 415V
S-300A260 Liter125 Kg200 Kg3 phase for 220V - 415V
S-350270 Liter150 Kg240 Kg3 phase for 220V - 415V
S-350A280 Liter150 Kg250 Kg3 phase for 220V - 415V
S-400300 Liter175 Kg280 Kg3 phase for 220V - 415V
S-400A330 Liter175 Kg280 Kg3 phase for 220V - 415V
S-450340 Liter200 Kg320 Kg3 phase for 220V - 415V
S-450A360 Liter200 Kg330 Kg3 phase for 220V - 415V

Product Certification

Payment Details for Offline Orders

  • Payment Terms : TT ,L/C ,PayPal
  • Minimum Order : 1 Piece(s)

Attachment

Video

    ATLAS STAR spiral mixer


Last Update : 2019-06-27
